SWITCH 2 POSITION OFF-ON

Description

Sierra push pull switches feature solid brass construction with stainless steel springs. 3/8″ Diameter mounting stem fits panels up to 1″ thick. 15 amp @12VDC, 25A @24VDC.
MP39400: used to control the same circuit from two locations.
MP39600: energizes two separate circuits in the ON position.
MP39640: first pull energizes circuit 1, second pull energizes circuit 2.
MP39570, MP39580, & MP39590: first pull energizes circuit 1, second pull energizes circuits 1&2.
MP39610 & MP39620: first pull energizes circuit 1, second pull energizes circuits 2&3.

Description: Off/On
Type: SPST
Terminals: 2 Screw
Knob: Chr/Brass
:
:

KMS Part# SIE MP39530
DMP Part# 54-1037
Vendor # MP39530
