PANEL 4-GANG VERTICAL SPLASH G REPLACES P/N 354-424016

Description

Splash Guard Vertical 4-Gang Rocker Switch Panel is constructed of fire resistant injection molded nylon. These panels are suitable for use in engine room compartments. Features six 15A 12VDC illuminated SPST On/Off rocker switches, six fuse holders for use with standard AGC 1/4” x 1-1/4” glass style fuses, and splash guard switch covers making this panel ideal for use where panel front might be subject to light spray and water (not designed for total immersion). Individual circuit 10A max. 37A total. 12VDC. Includes a sheet of 20 preprinted decals to customize to your specific applications and mounting gasket. Installs with six #6 RH fasteners (not included). Meets CE specifications.

KMS Part# SDG 4240161
Vendor Part# 424016-1
