Description
Ignition protected for installation on gasoline/diesel powered boats
Sealed cover protects fuses from the harsh marine environment and satisfies ABYC/USCG insulation requirements
Cover breakouts allow wire access in three directions
One-piece stainless flange nuts ensure safe and secure connections
Accepts square format standard or custom label
Fuses sold separatelySpecifications
Voltage Max. Operating 32V DC
Wire Size to Meet Rating #2/0 AWG (70 mmĀ²)
Mounting holes Accept 1Āā4″ (M6) Screws
Terminal Stud Size M8
Terminal Screw Size M5 Stainless Steel
